Standard Specifications

  • Diameters: 30"
  • Feeds: 84
  • Gauge: 14 to 28 Gauge (Number of needles in cylinder and dial)
  • Optimum operating speed
    R.P.M. depending on machine diameter and type of yarn used (MAXIMUM SPEED FACTOR 900)
  • 4 track cylinder and 2 track dial cams with completely closed cam system.
  • Delayed timing as standard, synchronized timing is available by means of exchange Cylinder cams.
SCM knitting / textile machine : interlock 2


With 4 Track Cylinder 2 Track Dial the following Additional Structure are possible

  • Diagonals in colour or relief. (Up to 28 Gauge)
  • Crepes
  • Vertical stripes
  • Small squares in colour or relief.
  • Multifeed stripes
  • Inlay fabric(26G-32G) by optional cams, yarns carriers etc.
  • Interlock plating under interlock construction (26G-32G)
    By optional plating yarn carriers etc.
  • Brush interlock fabric (18G-28G)
    By optional cams, yarn carriers etc.
  • Brush double pique (18G-28G)
    By optional cams, yarn carriers etc.
